Megan Blue Rear Sub-Frame Bushing Inserts For Gen1&2 FR-S BRZ ZC6 ZD8 GR86 ZN6 ZN8

Application:
Gen1
For 2013-2016 Scion FR-S
For 2013-2020 Subaru BRZ (ZC6)
For 2017-2020 Toyota 86 (ZN6)

Gen2
For 2022+ Subaru BRZ (ZD8)
For 2022+ Toyota GR 86 (ZN8)

Install Note:
Professional installation is required. Under lift high position jack stand required to hold rear Sub-Frame - Remove frame retaining bolts

Description & Feature
Megan Racing Rear Subframe Bushing Inserts eliminate go between the subframe and the chassis. These bushing insert will absorb energy, soften weight transfer by reducing rear frame movement. This makes for a solid and more connected ride that allows the rear-end to remain rigid and firm under stress or load.

• Material: Polyurethane Rubber
• Color: Blue
• Type: Sub-Frame Bushing Inserts
• Placement: Rear
• More response to the driver
• Remove frame retaining bolts
• Place 4 upper and 4 lower bushing inserts on top and below the 4 subframe bushings
• Torque frame retaining bolts at 72 ft.lb/s

Product Content:
8 x Sub-Frame Bushing Insert (4 Upper & 4 Lower)

No Instruction, Professional Install Recommended

Cross Reference Number:
MRS-SC-0692, MRS-SC-0692, MRSSC0692
