Turbocharger+Manifold+Wastegate For 98-04 Beetle/Golf/Jetta 1.9 TDI K04 GT1749V

Install Note:
Only Fits ALH Motors with Attached Manifolds

Description & Feature
This GT1749V Turbocharger is a direct replacement for the original turbo found on the 1993-2006 Audi A4 and Volkswagon Passat, Jetta and Golf 1.9L diesel engines. This turbocharger is not meant as an upgrade for the factory unit. It is offered as a solution for a turbocharger that is beyond repair and needs replacement at an affordable price. The GT1749V turbocharger is designed to be used on engines displacing 1.6L-2.5L and is typically good for around 300HP. Recommended boost pressures are 7psi(.5 Bar) to 21psi(1.5 Bar) and boost pressures should not exceed 30psi(2 Bar). Exceeding 21psi(1.5 Bar) of boost pressure can significantly reduce a turbochargers lifespan.

• Material: Cast Iron/Steel Turbo Housing/ Aluminum Controller
• Color: Metallic
• Surface Finish: Cast
• Boost engine horse power significantly. Increase engine power and torque outpout
• Maintain combustion chamber pressure and fuel/air load
• Built for durability and strength
• Intake Inlet/ Outlet: 1.6250" / 1.1875"
  Compressor A/R: 0.46
  Compressor Inducer/Exducer (MM): 48.50 / 64.00
  Compressor Trim: 50
  Exhaust (Downpipe) Flange: Standard GT1749V/ GT1749VA/ GT1749VB 3-Bolt
  Exhaust (Turbo Manifold) Flange: Standard Volkswagen K04 3-Bolt
  Turbine A/R: 0.61
  Turbine Inducer/Exducer (mm): 59.50 / 48.90
  Turbine Trim: 65
  Horse Power Increment: 300

Product Content:
1 x Turbocharger
1 x Turbo manifold
Hardware (Bolts/Gasket/Bracket) If Any is Shown in the Picture Above

No Instruction, Professional Install Recommended

Cross Reference Number:
BFC-TUBOC-GT1749V+TM
